VMIVME-HSD and VMIVME-HSDA are VMEbus interface board modules manufactured by Abaco Systems for connecting Encore HSD Model 9132 and Encore Model 9136 processors to VMEbus baseboards. They provide a high-performance 32-bit DMA link between VMEbus and Encore HSD processors.

Main features:

VMEbus Interface: Standard VMEbus P2 connectors are provided for integration with VMEbus systems.

HSD Processor interface: Connects to an Encore HSD Model 9132 or Encore Model 9136 processor via a proprietary interface.

DMA Transfer support: High-speed data transfer between VMEbus and HSD processors using DMA (Direct Memory access).

Interrupt handling: Support for interrupt handling to facilitate efficient communication between VMEbus and HSD processors.

Software support: Compatible with Abaco Systems’ IBL (Interrupt Agent Library) software to simplify interrupt management.

Applications:

The VMIVME-HSD and VMIVME-HSDA modules are primarily used in applications that require high-speed data transfer between the VMEbus system and the Encore HSD processor. Typical applications include:

Image processing systems: Capture and process image data from cameras and other imaging devices.

Signal processing systems: Process and analyze real-time signals from sensors and other data sources.

Data acquisition systems: Collect and transmit large amounts of data from various sources.

Scientific computing systems: Perform complex computing tasks that require high-speed data access.

Military and Aerospace Systems: Integration of Encore HSD processors into VMeBus-based military and aerospace applications.

VMIVME-HSD

Technical specifications:

The detailed technical specifications of the VMIVME-HSD and VMIVME-HSDA modules may not be publicly available unless you access Abaco Systems’ internal documentation or contact the manufacturer directly. However, based on the limited information available, some general specifications can be inferred:

Data transfer rate: up to 100 MB/s

Bus width: 32 bits

Interface standard: VMEbus P2, proprietary HSD processor interface

Software support: IBL (Interrupt Agent Library)
