IC693ALG392 is a 90-30 series module. This module is an analog output module that is commonly used to implement modulation control of instruments or devices, such as variable frequency drivers (VFDS), control valves, positioners, converters, and other similar modulation devices.

It can also be used to retransmit analog data to receiving elements such as loggers, data loggers and other compatible receiving devices.

The IC693ALG392 has eight (8) output channels and can be configured with a resolution of 15 or 16 bits, depending on the analog output range selected. It is capable of providing voltage signals such as 0 to +10 volts (unipolar) / -10 to +10 volts (bipolar) and 0 to 20 mA /4 to 20 mA output signals. In order to be able to generate an output analog signal, the module requires an isolated 24VDC power supply, connected directly to the specified terminal of the module.

IC693ALG392

The module is factory calibrated. Calibration information includes.625 μA from 0 to 20 mA; 0.5 μA from 4 to 20 mA; And.3125 mV voltage (per count). The module has an update rate of 8 (8) ms per channel at 4-20 mA and a resolution of 0.5 μA (1 LSB = 0.5 μA); 0-20 mA was 0.625 μA (1 LSB = 0.625 μA). The 0-10VDC output signal is 0.3125 mV (1 LSB = 0.3125 mV), and the -10 to +10VDC output signal is 0.3125 mV (1 LSB = 0.3125 mV).

The module is installed in any slot of the RX3i chassis. There is no limit to the number of instances allowed per RX3i rack. The number of instances depends on the amount of analog data supported by a particular RX3i controller.
