ProLinx Modbus Plus to Modbus Master/Slave Gateway Establishes a strong connection between devices on the Modbus Plus network and Modbus devices. This standalone DIN rail mounting protocol gateway offers one Modbus Plus port and up to four Modbus-enabled serial ports. The Modbus Plus protocol driver supports master and slave implementations of the protocol on the DB9 female Modbus Plus port. The Modbus Plus port is fully configurable. The Modbus protocol driver supports both master and slave implementations of the protocol. All Modbus serial ports can be configured individually to provide a very powerful and flexible host or device interface solution.

The MBP-MCM module is the ideal solution for many applications where the Modbus Plus connection can be used to integrate Modbus devices into the system. The Modbus Plus Gateway is a powerful module that supports both clients and servers and easily connects to Rockwell Automation PLCS (CLX, SLC, PLC, CPLX and similar devices). Combined with Modbus device support, this module provides a very powerful interface to many ASCII devices used in the industrial market today. Applications of this module have applications in most industries, especially manufacturing, oil and gas, power and food processing. Specifications Internal database The ProLinx module contains an internal database consisting of application data, status information, and configuration information areas. The internal database is shared between all ports on the module and is used as a conduit to pass information from devices on one network to one or more devices on another network. Application data areas Data areas are used to store and retrieve data through protocol drivers and for data exchange between protocols. The database is used as a source for writing commands to remote devices and holding data collected from remote devices. The commands defined in the configuration file (stored in the configuration data area) control how data is processed in the database. Status Data area This area is used to store error codes, counters, and port status information for each port. Configuration Data area This area contains module configuration information, such as port configuration, network information, and command configuration.

Compatibility: Compatible with MODBUS protocol
Communication interface: Multiple communication ports for seamless integration
Power supply: 24V DC
Operating temperature: -40℃~ 85℃
Overall dimensions: 150mm × 100mm × 50mm
