1769-IT6-A Compact I/O series of programmable controller modules

1769-IT6-A Compact I/O series of programmable controller modules

summarize

Allen-Bradley 1769-IT6 is a compact I/O family of programmable controller modules designed for thermocouple and millivolt input applications.

It has the following characteristics:

Six channels: Up to six thermocouples or other millivolt sensors can be connected.
Compatible sensor types: Support J, K, T, E, R, N, S, B, C, CJC and other thermocouple types.
Wide input range: can accept +/ -50mV and +/-10mV signals, operating range is -50 to +50mV and -10 to +10mV.
High accuracy: provides full scale accuracy of 0.1%.
Cold end compensation: Automatic cold end compensation to ensure measurement accuracy.
Filter: Filter function can be configured to reduce noise interference.
Diagnosis: Provides the fault diagnosis function to help users quickly identify and resolve problems.
Easy to use: Simple configuration software, easy to set up and use.

1769-IT6-A

Technical specification

Number of channels: 6
Input type: Thermocouple, millivolt
Compatible sensor types: J, K, T, E, R, N, S, B, C, CJC, etc
Input range: +/ -50mV, -50 to +50mV; +/-10mV, -10 to +10mV
Accuracy: 0.1% full scale
Cold end compensation: automatic
Filter: configurable
Diagnostic function: Supported
Communication: RS-232, RS-485
Power supply: 24V DC
Power consumption: < 5W
Operating temperature: -20°C to +60°C
Protection level: IP20
Dimensions: 90 x 30 x 25 mm
Weight: 0.2 kg
Apply

Allen-Bradley 1769-IT6 is suitable for a variety of applications where temperature needs to be measured and controlled, including:

Industrial automation: can be used to monitor and control the temperature in industrial processes, such as metallurgy, chemical industry, food processing, etc.
HVAC system: Can be used to control the temperature of the HVAC system.
Power plants: Can be used to monitor and control the temperature of power plants.
Laboratory: Temperature measurement that can be used to conduct scientific experiments.
