Technical specifications for IC660BBD024
Brand GE Fanuc
Series Genius module I/O
Part number IC660BBD024
Module type Discrete block I/O
Nooooo. Number of channels 32 (32); Configurable for input/output and output with feedback
Input voltage 12/24 V DC
Input Impedance 3.3k ohm
Input processing time (typical) 1.4ms (plus optional filter delay)
Input filter 1, 2, 3, 4, 5, 10, 20, 30, 40, 50, 60, 70, 80, 90 or 100 milliseconds
Maximum output current (steady state) 0.5 amps per circuit
Max surge current 4 amps, Max 10 ms (every 5 seconds, Max)
Module output current (total) 16 amps
The maximum output opening delay is 0.5 ms
Output diagnostic switch fault
Describes block I/O
Voltage 12/24 volts DC

The IC660BBD024 is a GE Fanuc intelligent Block I/O module. The module is a high-density thirty-two (32) point-discrete I/O module with individually configurable channels such as input, output, or output with feedback. The module supports source wiring and provides resetable self-protection circuitry and advanced diagnostic functions.

The IC660BBD024 input features include compatibility with 12/24VDC as the on-status signal value. Specifically, for 12VDC, the conduction range is 8-12VDc, while 18-24VDC is the 24VDC conduction state. It has an input impedance of 3.3 K ohms and an input processing time of 1.4 ms, subject to configured signal filtering, with a variety of options such as 1, 2, 3, 4, 5, 10, 20, 30, 40, 50, 60, 70, 80, 90 or 100 ms.

When configured as an output, each channel is capable of delivering 0.5 amps of current with a turn-on delay of 0.5 ms, and is capable of withstanding a maximum surge current of 4 amps for 10 ms, repeating every 0.5 seconds. This block I/O can reach 16 amps. Each configured output channel has a maximum voltage drop of 2.0 volts at 4 amp surges and is capable of detecting switch failures.

The IC660BBD024 supports the Genius Bus protocol for communication with partner devices that are compatible with the aforementioned protocols. Specifically, bus controllers such as IC66*CBB902 or CBB 903, any version; Or model IC66*CBB900 or CBB901 1.3 or higher. It can also be configured using the IC66*HHM501 handheld monitor. For Bus switch modules (BSM), IC66*BSM021 is compatible with IC660BBD024 block I/O.

The IC660BBD024 I/O block can also be used with 2-wire and 3-wire proximity switches as well as relays, contactors and lights. The 32 identical I/O points on the front panel can be easily configured. When a connection is established with the contact, the corresponding LED indicator next to the contact will light up. The GE Fanuc IC660BBD024 I/O block has a block-to-block isolation rating of 850 volts. The maximum ripple is 10% for 12 to 24 volts and 1% for 5 volts. The IC660BBD024 I/O block has a power voltage drop of 4 ms at 12 V and 20 ms at 24 V. During the installation of the block, ensure proper handling. The block comes with an open housing and should therefore be kept in a clean location free of air pollutants. It can be installed in an up or down position with at least 2 inches of space between adjacent blocks. The operating temperature range of the IC660BBD024 I/O block should be set between 0 and 60 degrees Celsius with a maximum humidity of 95% non-condensing humidity.
